MYD induction heating equipment for weld preheat, PWHT,thermal fitting, coating preheat, mold heat, liquid heat and reactor heating
ØModel and Technical Parameters
Model | MYD-40KW | MYD-50KW | MYD-60KW | MYD-80KW | MYD-100KW | MYD-120KW | |||||
Input Power | 3*380VAC (Default), 3*220VAC (Optional), 3*440VAC (Optional) | ||||||||||
Output Frequency | 2KHZ ~ 30KHZ | ||||||||||
Output Power | 40KW | 50KW | 60KW | 80KW | 100KW | 120KW | |||||
Input Current | 60A | 75A | 90A | 120A | 150A | 180A | |||||
Air Cooling | Heating size:¢100-1500mm | Size: 800*560*1350mm | |||||||||
DSP control | Max:900℃; Heating Speed: 5-400℃/min | Packing size:900*660*1560mm | |||||||||
6 Channels control | 10 curves recorder | Net weight: 120kg | Gross weight with parts: 155-260kg | ||||||||
Main parts | Induction coil | K Thermocouple | R-1006 Temperature Recorder | ||||||||
Connection cable | Insulation Blanket | Thermocouple Connection cable | |||||||||
ØInduction heater
ØTypes of coils
Soft cable coil（bear 180℃）：Suitable for high speed&low temperature heating.
High temperature soft cable coil（bear 500℃):Suitable for all kinds of parts heating.
Water cooling cable coil（bear 80℃）:Suitable for long time&high temperature heating.
Ring heating coil（bear 300℃):Suitable for rapid heating of tubular work-piece.
Clamp coil（bear 300℃):Suitable for small space tube rapid heating.
Soft blanket coil（bear 300℃):Suitable for rapid preheating of girth weld.
Fillet weld heating coil (bear 300 C): Suitable for rapid preheating of fillet weld.
Copper pipe coil（bear 800℃):Suitable for large tank, kettle and vessel tube long time and high temperature heating.
Clamp coil（bear 300℃):Suitable for small space tube rapid heating.
Blanket coil（bear 300℃):Suitable for rapid preheating of straight weld
Arc heating coil（bear 300℃):Suitable for large work-piece rotating heating.
ØHeaters and parts for choice
Goods Descriptions | Quantity | Unit Price (USD) | Amount | Remarks | |
1. | MYD-40KW heater | 1 | Air cooling | ||
2. | MYD-50KWheater | ||||
3. | MYD-60KW heater | ||||
4. | MYD-80KW heater | ||||
5. | 25m cable coil (air cooling) | 1 | |||
6. | 25m cable coil (water cooling) | ||||
7. | 25m cable coil (high temperature) | ||||
8. | Insulation blanket (800℃ 1500*600*50mm) | 2 | |||
9. | Insulation blanket (800℃ 900*600*50mm) | 2 | |||
10. | K type thermcouple with 2m cable | 6 | |||
11. | Thermocouple Extend Cable 10m | ||||
12. | Connection Cable for coil 10m | ||||
13. | ER-1006 Temperature recorder |
ØPacking details:
Heater packing: 900*660*1560mm, Gross weight: 155-200kg。Some other parts and insulation blanket need the additional packing.
ØAfter sales service:
1.Heater warranty 3 years. Equipment accessories are consumables, not within the scope of warranty.
2.From the date of ordering, every 6 months to call back. 24 hours telephone communication.
